High-voltage pulse capacitors
for electrical equipment
of various technological purposes
ÈÊ-2,5-100
ÈÌÏ-6-200
ÈÊ-6-250
ÈÊ-25-1
ÈÊ-25-3,9
External view of the high-voltage pulse capacitors produced by IPPT of NAS of Ukraine
ÈÌÏ-50-1
ÈÌÏ-10-100
ÈÊÏ-30-3,3;           ÈÊÏ-30-1,2
Special low-inductance capacitors in insulating casings
ÈÊÝ - 100 - 0,17
(Design 1)
ÈÊ -100-0,1
ÈÊÝ - 100 - 0,17
(Design 2)
Technical characteristics of high-voltage pulse capacitors
Capacitor
type
Uí,
kV
Ñí,
μF
L,
nH
Discharge mode
Weight,
kg
Size
of a casing,
mm
character
f,
Hz
Im,
kA
Δ
For the installations of various technological purposes
ÈÊ-2,5-100
2,5
100
80
Aperiodic
10
2
  -
10
159õ159õ235
ÈÌÏ-6-200
6
200
500
Oscillating
0,1
20
2,5
42
306õ150õ615
ÈÊ-6-250
6
250
400
Oscillating
0,2
10
10
38
310õ160õ500
ÈÌÏ-10-100
10
100
500
Oscillating
0,2
35
10
75
455õ305õ365
ÈÊ-25-1
25
1
135
Oscillating
1 - 4
5,5
4
13,5
170õ160õ285
ÈÊ-25-3,9
25
3,9
600
Oscillating
         *
3;  7
12
11
42
∅158, Íê=795
For the immersion well-bottom devices
ÈÊÏ-30-1,2
30
1,2
400
Oscillating
0,2 - 1
17
4
33
∅101,6; Íê=1350
ÈÊÏ-30-3,3
30
3,3
1200
Oscillating
0,3
5
20
37
∅140; Íê=797
Special low-inductance capacitors in insulating casings
ÈÊ-100-0,1
100
0,1
70




6,1
303õ124õ140

         **
75


Oscillating
0,002
40
11



        **
40


Oscillating
10
25
11


ÈÊÝ-100-0,17
100
0,17
70
Aperiodic
0,016
40
-
6
303õ124õ164
303õ124õ142
The presented types of capacitors are used as energy storage
of the equipment of various technological purposes
and electrophysical  installations intended for the research
Notes.      * - water cooling;         ** - working voltage;
                Uí - rated voltage;       Ñí - rated capacity;       L - inductance;
                f - charge-discharge repetition frequency;       Im - maximum current amplitude;
                Δ - voltage oscillation decrement.
The Institute can develop, produce, and supply the high-voltage pulse capacitors
with different characteristics upon the Client's request
