The Institute can develop, produce, and supply the high-voltage pulse capacitors
with different characteristics upon the Client's request
Series
of high-voltage pulse capacitors
with a common insulating casing
General view of the capacitor in an insulating casing
Technical characteristics of the series of high-voltage pulse capacitors
with a common insulating casing
Overall sizes of capacitors
Design 1
Design 2
Arrangement of leads on the capacitor cover
Design 1
Design 2
Capacitor
type
Uν,
kV
Ρν,
μF
L,
nH
Discharge mode
Design
character
f,
Hz
Im,
kA
Δ
ΘΜΟ-10-5
10
5
500
Aperiodic
10
5
  -
2
ΘΚ-10-20
10
20
300
Oscillating
0,5
5
10
2
ΘΜΟ-10-25
10
25
250
Oscillating
2
10
10
1
ΘΜΟ-10-30
10
30
250
Oscillating
1
10
10
1
ΘΜΟ-20-6,3
20
6,3
300
Oscillating
2
10
10
1
ΘΜΟ-20-8
20
8
300
Oscillating
1
20
10
2
ΘΜΟ-25-4
25
4
300
Oscillating
2
10
10
2
ΘΜΟ-25-5
25
5
300
Oscillating
1
20
10
1
ΘΜΟ-50-0,5
50
0,5
500
Oscillating
10
5
10
1
ΘΜΟ-50-1
50
1
400
Oscillating
2
10
10
1
ΘΜΟ-50-1,5
50
1,5
400
Oscillating
1
20
10
1
ΘΜΟ-70-0,71
70
0,71
500
Oscillating
1
20
10
1
ΘΜΟ-100-0,25
100
0,25
550
Oscillating
0,1
50
1,5
1
Notes.      * - water cooling;          ** - working voltage;
                Uν - rated voltage;       Ρν - rated capacity;       L - inductance;
                f - charge-discharge repetition frequency;       Im - maximum current amplitude;
                Δ - voltage oscillation decrement.
Weight of capacitors is 28 to 31 kg
